TIA Genio 520/720

The new Engicam module is a powerful IoT platform equipped with generative AI capabilities and advanced multimedia features. TIA Genio 520/720 is based on MediaTek® Genio 520/720 processor with 10 TOPS 8th Generation NPU, 3D GPU for real-time and high-performance applications.

CPU MediaTek® Genio 520/720
RAM LPDDR5@6400MTs
AI CAPABILITIES 10 TOPS NPU
DIMENSIONS 35 x 55 mm

Specifications

CPU

  • MediaTek® Genio 520/720
  • Manufacturer: MediaTek
  • NPU
  • GPU

Cores

  • ARM
  • 2x Arm Cortex-A78, up to 2.6 GHz
    6x Arm Cortex-A55, up to 2.0 GHz

Memory

  • LPDDR5@6400MTs
  • up to 16GB

Graphics & AI

  • -MediaTek 8th Generation 10 TOPS NPU
    -Arm Mali-G57 MC2 up to 1.1 GHz
    OpenGL ® ES 1.1, 2.0, 3.2
    Vulkan ® 1.0, 1.1
    OpenCL up to 2.2

Video Processing Unit Capabilities

  • 3840 x 2160@60 fps HEVC/H.264/VP9 decoder
    3840 x 2160@30 fps HEVC/H.264 encoder

Mass Storage

  • eMMC or UFS drive soldered on-board

Networking

  • 1x 1Gb Ethernet

USB

  • 1x OTG
  • 2x USB2
  • 1x USB3

PCIe

  • 1
  • PCIe interface Gen2/1-lane

Audio

  • I2S or analog (HP stereo + MIC) Interface

Peripheral Interfaces

  • UART
    SPI
    I2C
    GPIOs
    JTAG
    SDIO
    MIPI CSI 2x 4-lane
    RGMII option

Power Supply

  • single 5V

Operating Temperature

  • -40° up to 85°

Dimensions

  • 35 x 55 mm

Product availability

  • 2035

Documentation & Software

Access technical documents, software, and support resources.

Hardware manual

Fact Sheet

Technical Wiki & Design Resources

Online documentation and technical knowledge base for this product.
